Vertical Panel Mounting System

Dual-use in land for both agriculture and energy production can improve land use efficiency and increase crop production by over 30%. And it can provide an additional source of income for farmers, making it a financially attractive option.

  • Material:

    Q235 / Q355 / S350GD
  • Service life:

    ≥ 25 Years
  • Warranty:

    15 Years
Inquiry now
Product Detail

Vertical Panel Mounting System
Huge Energy Vertical Panel Mounting System, the structure is made of high-strength H-shaped carbon steel, providing stability and long service life. Its 90-degree vertical design maximizes land use efficiency and has a aesthetic appearance. The drop-in installation style significantly reduces construction time, making it suitable for agricultural and livestock applications.

Material: Q235 / Q355 / S350GD
Surface Treatment:
Hot Dip Galvanized / Zn-Al-Mg Coated
Warranty:
15 Years


Vertical Panel Mounting System


Advantages
  • Easy Installation
The module installation uses a drop-in design—simply place and release to complete installation. Unique round-head square-neck bolts feature self-locking and anti-rotation properties, significantly reducing on-site installation time.
  • Stable Structure and Adjustable Height

The mounting system made from high-strength carbon steel, ensuring stability and strong wind resistance. The height of the mounting system can be adjusted to suit site requirements, achieving optimal layout.


Vertical Panel Mounting System
Vertical Panel Mounting System


Project Case
Vertical Panel Mounting System

A Free Consultation

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
